Brr 20/Cary60

Peltier-controlled cuvette holder with extended low temperature response for the Cary 60 (or Cary 50) UV/Vis Spectrophotometer
Product Overview

The Brr 20/Cary60 is a temperature-controlled cuvette holder for the range of +110 °C down to -55 °C. It is designed for use in your Cary 60 (or Cary 50). Install the Brr 20/Cary60, by screwing it down in place in the sample compartment. Utilities may be routed through a small panel in the back of the spectrophotometer. Use the Brr 20/Cary60 to set and maintain precise sample temperatures and stir at a steady reproducible rate, while bathing the cuvette in a controlled gaseous environment. This product is provided with a windowed vest to enhance performance at low temperatures and minimize condensation that may form on the windows. Circulating water is used to remove heat from the Peltier heat exchanger. Purchase the extended temperature option to extend operation above 110 °C to 150 °C. Control the Brr 20/Cary60 using the TC 1B Temperature Controller, included in the purchase price. For additional control and temperature monitoring, use Quantum Northwest’s computer control software, T-App, available for purchase. Alternatively, use an ADL program for temperature ramping with WinUV ADL Shell software.

Product Features

Rapid, precise Peltier temperature control -55 °C to +110 °C
Precise stepper-motor-driven magnetic stirring
Dry gas purge for work at low temperature
Insulated lid to improve temperature stability
Threaded inserts to mount windows or filters
Cuvette lifter for removal of cuvette
Probe input for sample temperature
Mounting base and post for the Cary 60
NIST-traceable temperature calibration
ADL program for temperature ramping

  • Technical Specifications
    Number of cuvettes controlled
    Typical use
    Standard cuvette size (outside)
    12.5 mm x 12.5 mm
    Optical ports per cuvette
    Optical port dimensions
    12 mm high x 10 mm wide
    Cuvette z-height
    15 mm
    Windowed vest available
    Factory set temperature range
    -55 °C to +110 °C
    Temperature range easily achievable
    -55 °C to +110 °C
    Temperature precision
    ±0.02 °C
    Thermistor probes accepted
    Magnetic stirring motor type
    Magnetic stirring speed range
    1-2500 rpm
    Default stirring speed
    1200 rpm
    Stirring speed best performance
    60-1800 rpm
  • Basic Package

    Brr 20 – Temperature-controlled cuvette holder
    TC 1B – Temperature Controller
    Post and mounting plate
    NIST-traceable calibration and performance data
    Magnetic stir bar, tubing for water and dry gas, and cables
    ADL program for temperature ramping
