CD 250/Cary60
Temperature-controlled holder for the Cary 60 (or Cary 50) UV/Vis Spectrophotometer for a wide variety of cuvette types or solid samplesThe CD 250/Cary60 for the Cary 60 (or Cary 50) UV/Vis Spectrophotometer provides temperature control, dry gas purging and magnetic stirring as needed to a wide range of cuvettes or other samples. This versatility is accomplished using a cuvette carriage which firmly mounts within the temperature controlled tower of the CD 250/Cary60. Cuvette carriages are available for several kinds of cuvettes, including those that are square, rectangular or cylindrical, as well as other samples such as small plates or films. Other carriages can be inexpensively designed as needed. Fused silica windows may be placed on each side of the sample or cuvette to minimize convection losses. Depending on the carriage design, an additional optical port may be available at 90 degrees to the excitation. Use the CD 250/Cary60 for work in the biological range of 0 °C to 105 °C. With the correct carriage design and sample, extend temperature ranges to below -25 °C or up to 150 °C. Operate the TC 1/Single Temperature Controller using the menu button or control via program T-App. Use an ADL program for temperature ramping with WinUV ADL Shell software.
Accepts wide variety of cuvette types
Rapid, precise temperature control
Optional extended temperature range
Strain-free, fused-silica windows
Optional optical port at 90 degrees
Variable-speed magnetic stirring
Dry gas purge
Base for mounting in the Cary 60
Probe input for sample temperature
NIST-traceable temperature calibration
ADL program for temperature ramping
